Specifications:
The
FR 692-D1 is actually manufactured by
Pizzato Elettrica (often searched or confused under other industrial switch brands like Bernstein) as a
safety switch with a separate key actuator.
- Manufacturer: Pizzato Elettrica
- Product Type: Safety switch with separate actuator (key-operated, angled key)
- Contact Configuration: 1NO + 1NC (slow action)
- AC Contact Load Capacity: 3A / 400 VAC
- Housing Material: PBT technopolymer (polymer)
- Protection Rating: IP67 (dust-tight and protected against temporary immersion)
- Conduit / Cable Entry: One threaded PG 13.5 entry
- Operating Temperature: -25°C to +80°C
- Positive Opening: Yes (safety function)
- Dimensions: Approx. 93 x 30.8 x 30.8 mm (3.70″ x 1.21″ style body proportions
