Specifications:
Beckhoff 4-channel digital input terminal used to acquire 24 V DC binary control signals from machine sensors. The “-10” or custom suffix typically denotes a specific hardware version or factory customization for industrial automation for a Dynamic Edgebander.
Core Specifications
- Number of Inputs: 4 channels (digital)
- Nominal Voltage: 24 V DC (-15% / +20%)
- Signal Voltage “0”: -3 to +5 V DC (Type 2 specification)
- Signal Voltage “1”: 11 to 30 V DC (Type 2 specification)
- Input Current: Typical 6 mA
- Input Filter: Typical 3.0 ms
- Connection Technology: 2-wire sensor connection with direct +24 V feed points
- Electrical Isolation: 500 V (E-bus / field potential)
- Current Consumption E-bus: Typical 90 mA
