For use on grinding machines and other applications subject to particle laden coolant
Sense Directions: ±X, ±Y, +Z
Stylus overtravel: 15° X and Y directions 6,5mm (0.25in) Z direction.
Uni-directional Repeatability Max 2 Sigma (2σ ) value: Repeatability of 1,0µm (40µin) is valid for test velocity of 480mm/min (1.5ft/min) at stylus tip. Using a stylus 35mm (1.37in) long.
Stylus trigger force X and Y direction: Set at 0,5N / 50gf (1.76ozf) giving 0,9N / 90gf (3.17ozf) max
Z direction: 5,85N / 585gf (20.6ozf)
