Specifications:
The Gefran 1101-R0-1R-0-1-P97 F000368 is a microprocessor-based digital PID controller designed for precise thermal process monitoring and regulation in industrial automation.
- Format / Dimensions: 96 x 96 mm (1/4 DIN) square format.
- Supply Voltage: 100–240 VAC, 50/60 Hz.
- Display: Dual 4-digit green LED displays with red indicators for alarm statuses.
- Front Protection: IP54 frontal rating via Lexan membrane faceplate.
- Universal Inputs: Supports thermocouples (J, K, R, S, T, B, E, N), Pt100 3-wire resistance thermometers, and linear signals (0-50mV, 10-50mV, 0/2-10V, 0/4-20mA).
- Outputs: Relay and logic outputs, including configurable alarm relay outputs.
- Key Features: Self-tuning/auto-tuning, soft-start, and hardware jumper protection
