Specifications:
The Turck TBEN-S2-4AI is a compact multiprotocol Ethernet I/O module featuring 4 configurable analog input/temperature channels. It supports Modbus TCP, EtherNet/IP, PROFINET, and CC-Link IE Field Basic protocols in an IP65/IP67/IP69K rated fiberglass-reinforced housing.
Communication & Protocols
- Supported Protocols: Modbus TCP, EtherNet/IP, PROFINET, CC-Link IE Field Basic
- Transmission Rate: 10/100 Mbps
- Fieldbus Connection: 2 × M8, 4-pin
- Number of Inputs: 4 configurable analog inputs (voltage, current, RTD, or thermocouple)
- Signal Types: Voltage (0/2–10V, ±10V, etc.), Current (0/4–20mA), RTD (Pt100, Pt200, Pt500, Pt1000, Ni100, Ni1000), and Thermocouples (Types K, B, E, J, N, R, S, T, C, G)
- Supply Voltage: 24 V DC (admissible range 18–30 V DC)
- Current Consumption: 100 to 240 mA
- Dimensions: 144 mm × 32 mm × 32 mm
- Enclosure Material: PA6 fiber-reinforced glas
