SKU: 1174-65 CAD $36,000.00

Marcus MTWPH40A13 600KVA 600-230V 3PH Transformer

Specifications:

The Marcus MTWPH40A13 is a high-capacity, heavy-duty 600 kVA dry-type electrical distribution transformer manufactured by Marcus Transformer. Designed specifically for demanding three-phase power applications, this outdoor-rated model provides reliable stepped-down voltage transformation.

According to Marcus Transformer’s standard engineering guidelines and general product lineup data, the technical parameters for this specific model configuration are:

Model/Series: MTWPH40A13 (MTWPH Series: Three-Phase Outdoor)
Power Rating: 600 kVA
Phase: 3-Phase (3PH)
Frequency: 60 Hz (standard North American application; 50 Hz available upon request)
Primary Voltage (Input): 600 V
Secondary Voltage (Output): 230 V
Winding Material: 100% Pure Electrolytic Copper (Marcus signature feature for superior conductivity and thermal performance)
Enclosure Rating: NEMA 3R (Weatherproof, ventilated enclosure suitable for outdoor or indoor placement)
Cooling Method: Air-ventilated, dry-type design (ANN / self-cooled)
Insulation Class: Class H (220°C)
Temperature Rise: 150°C max rise under full continuous load
