Specifications:
The Rex Power Magnetics R10JC is a 3-phase dry-type autotransformer designed for efficient, step-down voltage transformation in commercial and industrial environments.
The technical specifications based on its catalog designation and standard configurations include:
Core Electrical Specifications
- Power Rating (Capacity): 10 kVA
- Number of Phases: 3-Phase (3 Ph)
- Primary Voltage: 600Y/347V AC (Wye)
- Secondary Voltage: 240/139V AC (Wye)
- Frequency: 60 Hz
- Transformer Type: Autotransformer (shared winding configuration for optimal voltage regulation and footprint efficiency)
- Winding Material: Aluminum
